Photo Gallery

- Symposium Photo Gallery -

- High Strength/Peformance Concrete in Japan -


  file #001 : Toyota Arrows Bridge
  infomation : Length：820 m
Span：173.4+2@235.0+173.4 m
Completed in March 2005
  offered by : Central Nippon Expressway Company Limited


  file #002 : Tensile deformation ability of ductile fiber reinforced cementitious composite
  infomation : Tensile strength：6MPa
Ultimate strain：3～4%
  offered by : Kajima Corporation


  file #003 : Flexural deformation ability of ductile fiber reinforced cementitious composite
  infomation : Bending strength：25MPa
  offered by : Kajima Corporation


  file #004 : Crushing behavior of hjgh-strength concrete under uni-axial compression test
  infomation : Compressive strngth：150MPa
  offered by : Kajima Corporation


  file #005 : Sakata Mirai Bridge
  infomation :
  offered by :


  file #006 : Application of high-strength and self-compacting concrete for continuous diaphragm wall of underground LNG tank
  infomation : Required Average Strength：80N/mm2　(91 days)
Slump Flow：650±50 mm
  offered by : Kajima corporation



  file #007 : W Comfort Towers
  infomation : completed in 2005
structure:Reinforced concrete
Tower East
stories: 54 stories
height:180m
maximum Fc:100N/mm2		 Tower West
stories:45 stories
height:150m
maximum Fc:80N/mm2
  offered by : Toda Corporation



  file #008 : Park City Musashi Kosugi ( as of May 28, 2007 )
  infomation : 59 story RC building using 150 MPa concrete ( the right side)
  offered by : Takenaka Corporation




  file #009 : Cutting section of real size RC column using 150 MPa concrete
  infomation :

Steel fiber was added in the 150 MPa concrete to prevent early spalling of the cover concrete
  offered by : Takenaka Corporation
